Application overview
RANGE BACKGROUND GAS TELEDYNE INSTRUMENTS SENSOR OPTIONS
Trace
Less than 1000 ppm CO2 in the background
gas
311, 316, 317, 318, 3160 B-2C
3000T series L-2C
More than 1000 ppm up to 100% CO2 in the
background gas
All trace oxygen
instruments
A-2C
Note: To use the A-2C or B-2C sensor in a 3000T series instrument, adapter part number B66378 is required.
Note: The L-2C sensor cannot be used in our older analog models (300 series).
Percent
Less than 1000 ppm CO2 in the background
gas
311P, 320A / P / BRC, 326,
327, 328
B-1, B-3 standard;
C-3 for high
concentration of O2
More than 1000 ppm up to 100% CO2 in the
background gas
A-5
Selecting a Teledyne Oxygen Sensor - Detail
CLASS
(click for spec
control drwg.)
PART No. APPLICATION COMMENTS
A-1
oxygen sensor
C6689-A1
Ultra-fast response (90% in less than 4
seconds) in the percent oxygen region.
Use only when B-1 response
time is insufficient.
A-2C
oxygen sensor
C6689-A2C
Used for trace O2 measurements in CO2
containing backgrounds (0.1-100% CO2).
CO2 must be present.
Use where acid gases are
present (CO2, HCl, HCN, etc).
CO2 must be present.
A-2CXL
oxygen sensor
B74033-A2CXL
Specially qualified A2C sensor to operate in
XL model analyzers. Low range limit is 0-1
ppm.
Use where acid gases are
present (CO2, HCl, HCN, etc).
CO2 must be present.
A-2Cl: Obsolete, use A-2C
A-3: Obsolete, use A-5
A-5
oxygen sensor
C6689-A5
Intermittent or continuous monitoring of
percent O2 in gas mixtures containing 0-
100% CO2. 90% response is time is 45
seconds.
Has more tolerance to exposure
to air than A-3. No restrictions
on CO2 concentration.
B-1
oxygen sensor
C6689-B1
General purpose percent oxygen analysis
where fast response is desired (90% in
less than 7 seconds).
Use B-3 or C-3 where longer life
is required and response time is
relatively unimportant. May be
used to spot check flue gas.
B-2C
oxygen sensor
C6689-B2C
General purpose trace O2 analysis for use
in inert gas and hydrocarbon streams. Low
range limit is 0-10 ppm.
May be used in CO2 free gas
streams containing highly
mobile gases such as H2, He
and ethylene.
INSTA TRACE
oxygen sensor
B71875
Special patented construction provides
rapid recovery, during initial cell installation,
to low PPM levels by reducing the recovery
period from several hours to just minutes.
Low range limit is 0-10 ppm.
Used for trace O2 analysis in
inert gas and hydrocarbon
streams.
B-2CXL
oxygen sensor
C6689-B2CXL
Specially qualified B-2C sensor to operate
in XL model analyzers. Low range limit is 0-
1 ppm.
May be used in CO2 free gas
streams containing highly
mobile gases such as H2, He
and ethylene.
B-3
oxygen sensor
C6689-B3
Percent O2 analysis, best compromise
between long life and fast response.
May be used to spot check flue
gas.
www.teledyne-ai.com/industrialsensors.asp 2/3
oxygen sensor between long life and fast response. gas.
B-4C
oxygen sensor
C14613-B4C
Trace O2 cell specifically designed for the
Model 317EXI.
Same performance as the B-2.
B-5
oxygen sensor
C45091-B5
Special application cell (non-standard)
where long life and moderately fast
response are required; B-5 has a factor of
3x the life of a B-3.
Requires 3x the amplifier gain of
the B-3. Expected life is 36
months in air.
B-5F
oxygen sensor
C45091-B5F
Special application cell (non-standard)
where long life and moderately fast
response, in the presence of CO2, are
required.
Uses Type F (acid electrolyte).
Requires higher amplifier gain
than normal. 90% response
time is 13 seconds. Expected
life in air is 6 months.
B-7
oxygen sensor
C45091-B7
Special application cell (non-standard)
where fast response is required; the B-7
has a factor of 3x the life of a B-1 cell.
Requires 3x the amplifier gain of
the B-1. Expected life in air is 24
months.
B-7F
oxygen sensor
C45091-B7F
Special application cell (non-standard)
where moderate life and fast response, in
the presence of CO2, are required.
Requires higher amplifier gain
than normal. 90% response
time is 7 seconds. Expected life
in air is 3 months.
C-1
oxygen sensor
C6689-C1 Rarely used. Schematic for reference only.
C-2
oxygen sensor
C6689-C2 Rarely used. Schematic for reference only.
C-3
oxygen sensor
C6689-C3
Percent O2 measurements where maximum
cell life is desired (high O2 applications).
90% response time is 30
seconds. Expected life in air is
18 months.
C-5
oxygen sensor
C45091-C5
Special application cell (non-standard)
where long life is required; the C-5 has a
factor of 3x the life of a C-3 cell.
Requires 3x the amplifier gain of
the C-3. Expected life in air is 54
months.
C-5F
oxygen sensor
C45091-C5F
Special application cell (non-standard)
where long life, in the presence of CO2, is
required.
Requires higher amplifier gain
than normal. 90% response
time is 30 seconds. Expected
life in air is 9 months.
C-6
oxygen sensor C54090-C6
Motion insensitive percent O2
measurements for use in hand held
portable monitors.
Best cell for OEM safety
applications.
E-1
oxygen sensor
C14991-E1
Special cell with performance characteristic
of the C-3 with 5x the life.
Cell is 2 to 3 times the length of
standard MFCs; requires special
mounting. Designed for medical
oxygen concentrators.
E-2
oxygen sensor
C57283-E2
Long life cell for use is the Model 3290 (for
use in unattended air liquefaction nitrogen
skids).
Has a 3 to 4 years expected life
in air. Minimum range 0-1000
ppm.
F-1R C40371-F1R 0-1000 ppm CO in Air
Used in Max 5 and 9950
Portable Combustion Analyzers
F-3 C55194-F3 Rarely used. Schematic for reference only.
INSTA TRACE -
CO2
B73016
Special patented construction provides
rapid recovery, during initial cell installation,
to low PPM levels by reducing the recovery
period from several hours to just minutes.
Used for trace O2 measurements in CO2
containing backgrounds (0-100% CO2) in
the 3000T analyzer series.
Use where acid gases are
present (CO2, HCl, HCN, etc).
CO2 must be present. The
INSTA TRACE Micro-fuel Cell
oxygen sensor is capable of
measuring below 1 ppm of
oxygen within 15 minutes of
installation.
INSTA TRACE -
XL
oxygen sensor
B73592
Special patented construction provides
rapid recovery, during initial cell installation,
to low PPM levels by reducing the recovery
period from several hours to just minutes.
Specially qualified sensor to operate in XL
model analyzers with a low range limit of 0-
1 ppm.
Used for trace O2 analysis in
inert gas and hydrocarbon
streams.
K-1
oxygen sensor
C43832-K1
Smallest Micro-fuel Cell, for use in
applications where small size or multiple
sensing requirements exist.
OEM applications; PC board
mountable.
K-2: Obsolete
L-2C
oxygen sensor
C6689-L2C
Used for general purpose trace oxygen
analysis in the 3000T analyzer series.
Has a 2 year expected life.
L-2CI
oxygen sensor
C6689-L2CI
Used in the Model 3000T series for trace
O2 measurements; use only in CO2 and H2
background mixtures (e.g. inert gas
CO2 concentration should be
within +/-20% about some
www.teledyne-ai.com/industrialsensors.asp 3/3
oxygen sensor background mixtures (e.g. inert gas
generators).
nominal concentration.
S-2C
oxygen sensor
C6689-S2C
Trace oxygen cell for use in TurbO2
analyzer. Provides rapid recovery from air
calibration (approximately 20 minutes).
Low range limit is 0-100 ppm.
Has three pin contact system.
Z-2C
oxygen sensor
C6689-Z2C
Has the same features as the S-2, except
configured for use in the Model 3190.
Low range limit is 0-100 ppm.
Has normal Micro-fuel Cell
contact plate.
