Standard Accessories
All models are shipped with drain/vent valves, and one instruction
manual per shipment.
Tagging
The transmitter will be tagged, at no charge, in accordance with
customer requirements. All tags are stainless steel. The standard
tag is wired to the transmitter, however a permanently attached tag
is available upon request. Tag character height is 0.125 in. (0.318
cm).
Calibration
Transmitters are factory calibrated to the customer’s specified
range. If calibration is not specified, the transmitters are calibrated
at maximum range. Calibration is performed at ambient
temperature and pressure.
Options
The following sections describe a variety of available options for
the 1151 Transmitter. These options permit greater application
flexibility.
Optional Manifolds
Refer to Manifold Product Data Sheet (document number
00813-0100-4839).
Optional Diaphragm and Sanitary Seals
Refer to Product Data Sheet (document numbers
00813-0100-4016 or 00813-0201-4016)
Mounting Brackets
B1 Bracket for 2-in. Pipe Mounting
• Bracket for mounting transmitter on 2-in. pipe
• Constructed of carbon steel with carbon steel U-bolt
• Coated with polyurethane paint
B4 Bracket for 2-in. Pipe with 316 SST Bolts
• Same bracket as Option Code B1 with 316 SST bolts
B7 304 SST Bracket and 316 SST Bolts for 2-in. Pipe Mounting
• Same bracket as Option Code B1 with all SST materials
B2 Bracket for Panel Mounting
• Bracket for mounting transmitter on panel or wall
• Constructed of carbon steel with
carbon steel bolts
• Coated with polyurethane paint
B5 Bracket for Panel with 316 SST Bolts
• Same bracket as Option Code B2
with 316 SST bolts
B3 Flat Bracket for 2-in. Pipe Mounting
• Bracket for vertical mounting of transmitter on 2-in. pipe
• Constructed of carbon steel with
carbon steel U-bolt
• Coated with polyurethane paint
B6 Flat Bracket for 2-in. Pipe with 316 SST Bolts
• Same bracket as Option Code B3
with 316 SST bolts
B9 304 SST Flat Bracket and 316 SST Bolts for 2-in. Pipe
Mounting
• Same bracket as Option Code B3 with all 316 SST materials
Bolts and Nuts for Flanges and Adapters
Options permit bolts and nuts for flanges and adapters in the
specified material.
• L3 ANSI/ASTM A - 193-B7
• L4 Austenitic 316 SST
• L5 ANSI/ASTM A193-B7M
Meters
Analog
• Meters have 2-in. (50.8 mm) scale
• Plug-in mounting configuration
• Indication accuracy ±2%
• Operating temperature limit: –40 to 150 °F (–40 to 65 °C)
• Meters are enclosed in a housing certified by Factory Mutual
as Explosion-Proof for Class I, Division 1, Groups B, C, and D;
Class II, Division 1, Groups E, F, and G and Class III, Division
1
• For optional CSA explosion-proof approval, see certification
Option Code E6
• M1 Linear Analog Meter, 0–100% Scale
• M2 Square Root Analog Meter, 0–100% Flow Scale
• M3 Special Scaling Analog Meter (Specify Range)
• M6 Square Root Analog Meter, 0– 10√ Scale
LCD
• 4-digit display
• Indication accuracy ±0.25% of calibrated span ±1 digit
• Display resolution at ±0.5% of calibrated span ±1 digit
• Operating temperature limit: –4 to 158 °F (–20 to 70 °C)
• Plug-in mounting configuration
• Meters are enclosed in a housing certified by FM as
Explosion-Proof for Class I, Division 1, Groups B, C, and D;
Class II, Division 1, Groups E, F, and G and Class III, Division 1
• For Optional CSA explosion-proof approval, see certification
Option Code E6
• Reverse output not available with LCD Display
• M4 Linear LCD Meter, 0 to 100%
• M7 Special Scale LCD Display
(Specify Range, Mode, and Engineering Units)
• M8 Square Root LCD Display, 0 to 100%
• M9 Square Root LCD Display, 0–10√ Scale
