Endress+Hauser Microwave flow indicator Solimotion FTR20

Update: 2016/5/30      View:
  • Brand:    Endress+Hauser
  • Type:    FTR20
  • Order Online
Introduction

For monitoring pneumatic and mechanical transport processes for bulk solids

The Solimotion FTR20 flow indicator for bulk solids is a non-contact device based on microwave technology. It is ideally suited for cost-effective monitoring of a mass flow (present or not present). The compact device can be used wherever the cost-effective monitoring of bulk solids movement is required. Individual adjustments to the application can be carried out by means of configurable functions (incl. automatic calibration).

Benefits

  • Sensor, transmitter and power unit mounted in one housing, which means less effort for installation and mounting

  • High safety level compliant with international explosion protection certificates

  • Flush-mounted installation, non-contact installation possible for ideal integration into the process

  • Electronics housing can be rotated by 360° allowing adjustment into optimum position after installation

  • High cost-effectiveness thanks to its mechanical robustness: No wear, process-wetted ceramic sensor diaphragm (optional), long service life, maintenance-free

  • Signaling of mass flow (present or not present)

Field of application

Building materials industry: Cement, plaster, wood chips etc.
Chemicals: Fertilizers, plastic powder and granules, silica etc.
Food industry: Coffee, tea, tobacco, cereals, animal feeds etc.
Energy production: Coal, carbon dust, fly-ash, coke etc.

  • Process connections: Threads or a suitable mounting bracket

  • Temperature: -40 to +450°C (-40 to +842°F), with adapter for temperature reduction

  • Pressure: 0.5 to 6.8bar abs standard (7.2 to 98.6psi abs)

  • International explosion protection certificates

Measuring Principle Microwave barrier
Characteristic / Application The flow indicator for bulk solids is a non-contact device based on microwave technology. It is ideally suited for monitoring pneumatic and mechanical transport processes for bulk solids.
Ambient temperature -40°C ... +70°C
(-40°F...158°F)
Process temperature Standard
-40°C ... +70°C
(-40°F ...158°F)

With adapter for temperature reduction:
-40°C to +450°C
-40°F ...+842°F)

Process pressure absolute / max. overpressure limit 0.5 ... 6.8 bar abs standard
(7.2 ... 98.6 psi abs)

When using the adapter for temperature reduction:
0.8 to 5.1 bar abs
(11.6 ...74 psi abs)
Main wetted parts 316Ti/1.4571
Sensor diaphragm: PTFE or ceramic
Process connection Thread R 1½ (EN 10226)
NPT 1½ (ASME B1.20.1)
Communication Relay SPDT
Analog 4 - 20 mA
Solid-state relay

Certificates / Approvals ATEX, CSA C/US, IECEx

Options adapter for temperature reduction
