Yokogawa Vnet/IP Interface Card VI702

Update: 2016/5/24      View:
  • Brand:    Yokogawa
  • Type:    VI702
  • Order Online
Introduction
Yokogawa Vnet/IP Interface Card VI702

Product Specifications/Features
    Protection Level: IP54
    Type: Junction Box
    External Size: 111.15 x 167.65 mm
    FUNCTION: Interface between the PCI Express and Vnet/IP
    Communication Speed: 1 Gbps Full Duplex
    Cable: CAT5e (Enhanced Category 5 cable), UTP
    Transmission: 1000BASE-T compliance
    Connector: RJ45 connector
    Max. distance: 100 m (Distance between VI702 and Layer 2 switch)
    Power supply voltage: 3.3 V ± 9 %
    Current Consumption: Max. 2.5 A
    Weight: Approx. 0.18 kg
    Regulartory Compliance: EMC Standards


    Yokogawa Vnet/IP Interface Card VI702,Interface between the PCI Express and Vnet/IP,Certificate of Origin

    Yokogawa Vnet/IP Interface Card VI702

    By installing the control bus interface card into the PCI Express slot of the PC/AT compatible computer, the computer is connected to Vnet/IP.

    FUNCTION

    Interface between the PCI Express and Vnet/IP

    SPECIFICATIONS

    For conforming standards of the CENTUM VP system, see “System Overview (Vnet/IP Edition)” (GS 33L01A10-40E).

    Communication Speed

    1 Gbps Full Duplex

    Connection Specifications

    Cable: CAT5e (Enhanced Category 5 cable), UTP

    Transmission: 1000BASE-T compliance

    Connector: RJ45 connector

    Max. distance: 100 m (Distance between VI702 and Layer 2 switch)

    PCI Express Specifications

    Applicable revision: PCI Express CEM Specification 1.0a x1, 2.5 GT/s signaling

    This card can be installed in a PCI Express slot (x1 to x16).

    This card cannot be installed in a PCI slot.

    Voltage

    Power supply voltage: 3.3 V ± 9 %

    Current Consumption

    Max. 2.5 A

    Weight

    Approx. 0.18 kg

    External Dimensions

    111.15 x 167.65 (mm)

    Regulartory Compliance

    EMC Standards:

    [CE Marking]

    [C-Tick Marking]

    PARTS NAME AND FUNCTIONS

    RDY lamp

    Lights when it diaghoses the card as normal.

    RCV lamp

    Lights when it detects signals on a control bus.

    SND lamp

    Lights when it sends signals to a control bus.

    Ethernet connector

    Connects a CAT5e (Enhanced Category 5 cable)

    COMPATIBILITY WITH VI701

    The Vnet/IP interface of VI702 is compatible with VI701 card so that the VI701 card and VI702 card can be installed together in a same bus. Moreover, setting the domain number and station number of a VI702 card can be performed in a same way as for a VI701 card.

    Model and Suffic Code

    Model

    Description

    VI702

    Vnet/IP Interface Card
