Proline Promag 10D Electromagnetic flowmeter
- Brand: Endress+Hauser
- Type: 10D
The highly cost-effective flowmeter designed as compact wafer version
Promag D, the wafer device is designed for all applications where space is at a minimum. Combined with the Promag 10 transmitter for basic applications and direct integration, Promag 10D offers accurate measurement of liquids for a wide range of applications. It will be the preferred solution for customers in the water industry aiming for minimized cost of ownership. Promag 10D is available in a compact or remote version.
Benefits
-
Easy, fast centering of the sensor – innovative housing construction
-
Energy-saving flow measurement – no pressure loss due to cross-section constriction
-
Cost-effective – designed for easy applications and direct integration
-
Safe operation – display provides easy readable process information
-
Fully industry compliant – IEC/EN/NAMUR
-
Maintenance-free – no moving parts
Field of application
-
The measuring principle is virtually independent of pressure, density, temperature and viscosity
-
For basic water applications; optimized for limited space and plastic pipe installations.
Device properties
-
Short installation length and low weight
-
Integrated ground disks made of stainless steel
-
International drinking water approvals
-
2‐line display with push buttons
-
Device in compact or remote version
-
HART
| Measuring Principle | Electromagnetic | |
| Product headline |
The highly cost‐effective flowmeter, available as compact wafer. For basic water applications; optimized for limited space and plastic pipe installations. |
|
| Sensor features |
Easy, fast centering of the sensor – innovative housing construction. Energy‐saving flow measurement – no pressure loss due to cross‐section constriction. Maintenance‐free – no moving parts. Short installation length and low weight. Integrated ground disks made of stainless steel. |
|
| Transmitter features |
Cost‐effective – designed for easy applications and direct integration. Safe operation – display provides easy readable process information. Fully industry compliant – IEC/EN/NAMUR. 2‐line display with push buttons. Device in compact or remote version. |
|
| Nominal diameter range |
DN 25 to 100 (1 to 4") |
|
| Wetted materials |
Liner: Polyamide Electrodes: 1.4435 (316L) |
|
| Measured variables |
Volume flow |
|
| Max. measured error |
Volume flow: ±0.5 % o.r. ± 2 mm/s (±0.5 % o.r. ± 0.08 in/s) |
|
| Measuring range |
9 to 4700 dm3/min (2.5 to 1250 gal/min) |
|
| Max. process pressure |
PN 16, Class 150, 10K |
|
| Medium temperature range |
0 to +60 °C (+32 to +140 °F) |
|
| Ambient temperature range |
–20 to +60 °C (–4 to +140 °F) |
|
| Sensor housing material |
AlSi10Mg, coated Sensor connection housing: AlSi10Mg, coated |
|
| Transmitter housing material |
Powder‐coated die‐cast aluminum |
|
| Degree of protection |
Compact version: IP66/67, type 4X enclosure Sensor remote version: IP66/67, type 4X enclosure Transmitter remote version: IP67, type 4X enclosure |
|
| Display/Operation |
2‐line display with push buttons Configuration via local display and operating tools possible |
|
| Outputs |
4‐20 mA HART (active) Pulse/switch output (passive) |
|
| Inputs |
None |
|
| Digital communication |
HART |
|
| Power supply |
DC 11 to 40 V AC 85 to 250 V (45 to 65 Hz) AC 20 to 28 V (45 to 65 Hz) |
|
| Hazardous area approvals |
FM CSA |
|
| Other approvals and certificates |
Calibration performed on accredited calibration facilities (acc. to ISO/IEC 17025), NAMUR Drinking water approval: ACS, KTW/W270, NSF 61, WRAS BS 6920 |
|
