HART, PROFIBUS PA or FOUNDATION Fieldbus

Application
The Cerabar S pressure transmitter is used for the
following measuring tasks:
• Absolute pressure and gauge pressure in gases, steams
or liquids in all areas of process engineering and
process measurement technology
• Level, volume or mass measurements in liquids
• High process temperature
– without diaphragm seals up to 150 °C (302 °F)
– with typical diaphragm seals up to 400 °C (752 °F)
• High pressure up to 700 bar (10500 psi)
• MID part certificate as per OIML R117-1 Edition 2007
(E) and EN 12405-1/A1 Edition 2006
• International usage thanks to a wide range of approvals

Your benefits
• Very good reproducibility and long-term stability
• High reference accuracy: up to ±0.075 %,
as PLATINUM version: ±0.05 %
• Turn down up to 100:1, higher on request
• Used for process pressure monitoring up to SIL3,
certified to IEC 61508 by TÜV SÜD
• HistoROM®/M-DAT memory module
• Function-monitored from the measuring cell to the
electronics
• Continuous modularity for differential pressure,
hydrostatics and pressure (Deltabar S – Deltapilot S –
Cerabar S), e.g.
– replaceable display
– universal electronics
• Quick commissioning with Quick Setup menu
• Menu-guided operation
• Extensive diagnostic functions
• Device versions compliant with ASME-BPE
• Usage in drinking water: NSF
