Two-electrode sensors with cell constant k = 10 cm-1
Application Measurements in media of high or medium conductivities: • Process water • Wastewater treatment • Concentrate monitoring The cell constant k of the sensor is 10 cm–1. The measuring range reaches from 0.1 mS/cm to 200 mS/cm. Sensors with temperature sensors are used together with conductivity transmitters equipped with automatic temperature compensation: • Mycom S CLM153 • Liquisys M CLM223/253 • Liquiline M CM42 Your benefits • Various designs guarantee optimum adaptation to the process conditions and methods of installation • Installation in pipes or flow chambers • High chemical, thermal and mechanical stability • Compact design • Quality certificate with statement of the individual cell constant
• Electrodes The sensor electrodes are made of special graphite. The graphite guarantees high chemical stability and low polarization effects. • Accuracy The electrodes are built into a lateral measuring duct and shielded by a Teflon® sleeve. This prevents electrical leakage and guarantees constant, accurate measurements. • Durability – The PP version of the sensor is pressure-proof up to 16 bar at 20 °C (232 psi at 68 °F) and can be applied with temperatures of up to 90 °C (194 °F). – The PTFE version of the sensor is pressure-proof up to 6 bar at 20 °C (87 psi at 68 °F) and can be applied with temperatures of up to 125 °C (257 °F).
Measuring ranges Temperature sensor Pt 100 Cable specification The CLS30 sensor is connected to the transmitter via the fixed cable. a0009371-en Fixed cable To extend the connection, an RM junction box and a CYK71 extension cable is required. After the RM junction box, the Pt 100 temperature sensor must be connected by three wires. 1 3 2 Conductivity (referred to water at 25 °C (77 °F): 0.1 mS/cm to 200 mS/cm Temperature: PTFE version: PP version: -10 to 125 °C (14 to 257 °F) -10 to 90 °C (14 to 194 °F)
