Allen Bradley LDC-Series & LDL-Series Linear Servo Motors

Update: 2017/6/23      View:
  • Brand:    Allen Bradley
  • Type:
  • Order Online
Introduction

Features

  • No-wear parts such as bearings, gears, and belts
  • Connects directly to the payload that needs to be moved
  • Maintains quick movement while handling multiple motion profiles
  • Sizes and optimizes linear motors and corresponding servo drives using Motion Analyzer software
  • Full setup and programming support through RSLogix™ 5000 software (version 20 or earlier)
  • Achieves precise linear positioning at very high speeds

  • Provides very high speeds and acceleration for increased throughput of your machine

Catalog Number Description
LDC-C030100-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 30 Width, 100mm (4.15 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C030100-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 30 Width, 100mm (4.15 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C030200-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 30 Width, 200mm (8.30 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C030200-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 30 Width, 200mm (8.30 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C030200-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 30 Width, 200mm (8.30 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C030200-EHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 30 Width, 200mm (8.30 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C050100-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 100mm (4.15 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C050200-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 200mm (8.30 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C050200-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 200mm (8.30 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C050200-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 200mm (8.30 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C050300-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 300mm (12.45 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C050300-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 300mm (12.45 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C050300-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 300mm (12.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C075200-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 200mm (8.30 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C075200-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 200mm (8.30 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C075200-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 200mm (8.30 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C075200-EHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 200mm (8.30 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C075300-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 300mm (12.45 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C075300-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 300mm (12.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C075300-EHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 300mm (12.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C075400-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 400mm (16.60 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C075400-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 400mm (16.60 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C100300-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 100 Width, 300mm (12.45 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C100300-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 100 Width, 300mm (12.45 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C100300-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 100 Width, 300mm (12.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C100300-EHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 100 Width, 300mm (12.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C100400-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 100 Width, 400mm (16.60 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C100400-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 100 Width, 400mm (16.60 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C100600-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 100 Width, 600mm (23.62 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C100600-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 100 Width, 600mm (23.62 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C150400-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 150 Width, 400mm (16.60 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C150400-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 150 Width, 400mm (16.60 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C150400-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 150 Width, 400mm (16.60 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDC-C150600-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 150 Width, 600mm (23.62 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C150600-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 150 Width, 600mm (23.62 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDC-C150600-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 150 Width, 600mm (23.62 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-N030120-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 30 Width, 120mm (4.72 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-N030120-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 30 Width, 120mm (4.72 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-N030240-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 30 Width, 240mm (9.45 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-N030240-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 30 Width, 240mm (9.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-N030240-EHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 30 Width, 240mm (9.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-N050120-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 120mm (4.72 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-N050240-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 240mm (9.45 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-N050240-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 240mm (9.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-N050240-EHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 240mm (9.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-N050360-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 360mm (14.17 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-N050360-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 360mm (14.17 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-N050360-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 360mm (14.17 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-N050480-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 480mm (18.90 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-N050480-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 480mm (18.90 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-N050480-EHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 50 Width, 480mm (18.90 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-N075480-DHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 480mm (18.90 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-N075480-DHT20 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 480mm (18.90 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-N075480-EHT11 LDC and LDL Series Linear Servo Motors, Standard Coil, 75 Width, 480mm (18.90 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-T030120-DHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 30 Width, 120mm (4.72 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-T030120-DHT20 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 30 Width, 120mm (4.72 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-T030240-DHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 30 Width, 240mm (9.45 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-T030240-EHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 30 Width, 240mm (9.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-T030240-EHT20 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 30 Width, 240mm (9.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-T050120-DHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 50 Width, 120mm (4.72 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-T050120-DHT20 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 50 Width, 120mm (4.72 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-T050240-DHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 50 Width, 240mm (9.45 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-T050240-EHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 50 Width, 240mm (9.45 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-T050360-DHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 50 Width, 360mm (14.17 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-T050360-EHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 50 Width, 360mm (14.17 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-T050480-DHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 50 Width, 480mm (18.90 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-T050480-DHT20 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 50 Width, 480mm (18.90 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-T050480-EHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 50 Width, 480mm (18.90 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-T050480-EHT20 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 50 Width, 480mm (18.90 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
LDL-T075480-DHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 75 Width, 480mm (18.90 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-T075480-DHT20 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 75 Width, 480mm (18.90 in.), D Winding (High Speed), Hall Effect (Trapezoidal)
LDL-T075480-EHT11 LDC and LDL Series Linear Servo Motors, Thick Coil (High Force), 75 Width, 480mm (18.90 in.), E Winding (Low Speed), Hall Effect (Trapezoidal)
