Endress+Hauser 92F Ultrasonic flowmeter

Update: 2016/5/10      View:
  • Brand:    E+H
  • Type:
  • Order Online
Introduction

The world 's leading manufacturer of process automation , Endress + Hauser, launched the world's first two -wire pipe ultrasonic flowmeter Proline the Prosonic E+H Proline Prosonic Flow 92F E+H Proline Prosonic Flow 92FFlow 92F . Another masterpiece in the field of flow measurement as 2006 , the Prosonic Flow 92F called liquid measuring all-rounder .

The Prosonic Flow, 92F ultrasonic flow meter of the pipeline is the world's first circuit power supply ( two wire ) , this feature makes it easier with the system integration and to provide more cost-effective . The precision cast stainless steel sensor can achieve high measurement accuracy of ± 0.3% of the volume flow measurement accuracy is the highest standard for such products.




The Prosonic Flow, 92F is the ideal flow meter for measuring a variety of conductive and non conductive raw materials . In particular, makes it wide range of applications in chemical and petrochemical industry , measurement and conductivity of independence.


Only a combination of: safety , accuracy and cost-effective
 measurement of conductive and non- conductive materials and chemicals of the chemical and petrochemical industry
 two -wire transmitter , saving installation costs
 save installation space (up to 5D of straight pipe )
 without any baffles , an insignificant pressure loss
 There is no moving parts , maintenance-free
 Smart debug mode , improve the efficiency of plant maintenance

Technical indicators:
The Prosonic flow 92 ( transmitter )
 Display: two – line LCD button operation
 Power: non- explosion-proof 12 ~ 36VDC Explosion-proof 12 ~ 30VDC
 Degree of protection : IP67 (NEMA 4X )
 Design: one and split design
 Number of channels: 2, 3, 4 channel
 Output: current , pulse / frequency output
 Communication : HART Profibus PA
 Measuring accuracy: standard ± 0.5 % o.r
Optional ± 0.3 % o.r
 explosion-proof certification : the ATEX , FM, / CSA , NEPSI

The Prosonic flow 92 ( sensor )
 Diameter range : DN25 ~ 300
 Process Connection : EN (DIN ) , ANSI,
 pressure rating : PN16/40 , Cl 150 / 300
 Process Temperature : -40 ~ to +150 oC,
 Degree of protection : IP67 (NEMA 4X )
Optional IP68 ( NEMA 6P )
 material : welded stainless steel

 pressure loss : an insignificant
