Fisher 67CF Series Filter Regulators

Update: 2016/5/24      View:
  • Brand:    Fisher
  • Type:    67CF
  • Order Online
Introduction

✰ Compact and Light Weight

✰ Rugged Construction

✰ High Performance

✰ Internal Relief Valve

✰ Integral Filter

✰ No Air Loss

✰ Easy Maintenance


Introduction The 67CF Series regulators are typically used to provide constantly controlled, reduced pressures to pneumatic and electropneumatic controllers and other instruments. These direct-operated regulators are suitable for most air or gas applications. Other applications include providing reduced pressures to air chucks, air jets, and spray guns.

Features

• Compact—The 67CF Series regulators are engineered for outstanding performance in a compact, light-weight package. • Internal Relief—The Type 67CFR has an internal relief valve with a soft seat for reliable shutoff with no discernible leakage.

• Panel Mounting—Panel mount construction includes spring case with 1/4-inch NPT vent, handwheel adjusting screw, and mounting nut.

• Instrument Supply Regulator—Provides a clean air supply to a variety of pneumatic and electropneumatic instrumentation.

• Digital Instrument Supply Regulator—Designed for the accuracy, repeatability, and hysteresis demands of digital instrumentation.

• Pilot Supply Regulator—Improves the accuracy of two-path control regulators by reducing inlet sensitivity caused by fluctuating inlet pressures.

 • Pressure Loading Regulator—Provides high accuracy and improved performance in dirty steam service by eliminating the need for a pilot regulator (see figure 2).

• Sour Gas Service Capability—NACE (MR0175) compliant construction available.

• Integral Filter—An integral filter ensures clean downstream air supply.

• Ease of Maintenance—No special tools are required to perform maintenance, and all maintenance can be performed with the regulator in the line. Filter elements are easily replaced. The one-piece valve plug cartridge allows easy inspection and replacement.

• Rugged Construction—The 67CF Series regulators are engineered for longer service life with minimal maintenance requirements.

• Second Outlet—Body side outlet for pressure gauge or other uses.

• Powder Paint Coating—Fisher products are powder paint coated, offering impact, abrasion, and corrosion resistance.

• Corrosion Resistant Fasteners—Adjusting screw and screws are double zinc-chromated for enhanced corrosion resistance.

• Full Usable Capacity—Fisher regulators are laboratory tested. 100 percent of the published capacities can be used with confidence.
