Endress+Hauser LPGmass Coriolis flowmeter

Update: 2016/5/30      View:
  • Brand:    Endress+Hauser
  • Type:
  • Order Online
Introduction

The refueling and distribution application flowmeter with easy system integration

The LPGmass is specially designed for flow measurement of LPG for dispensing and truck unloading. It combines an integrated temperature measurement with intelligent conversion functions, providing volume correction directly on site. LPGmass will be the preferred choice for system integrators, skid builders and equipment manufacturers.

Benefits

  • Excellent operational safety – reliable under extreme ambient conditions

  • Fewer process measuring points – multivariable measurement (flow, density, temperature)

  • Space-saving installation – no in/outlet run needs

  • Easy operation – reduced to application needs

  • Fast commissioning – pre-configured devices

  • Automatic recovery of data for servicing


Field of application

  • Measuring principle operates independently of physical fluid properties such as viscosity or density

  • Accurate measurement of liquefied petroleum gas in refueling and distribution applications.

Device properties

  • Flow rates up to 45 000 kg/h (1654 lb/min)

  • Volume flow calculation according to API table 53

  • Worldwide metrological approvals

  • Robust, ultra-compact transmitter housing

  • Pulse output and Modbus RS485

  • Transmitter for custody transfer

Measuring Principle Coriolis
Product headline The refueling and distribution application flowmeter with easy sytem integration. Accurate measurement of liquefied petroleum gas in refueling and distribution applications.
Sensor features Excellent operational safety – reliable under extreme ambient conditions. Fewer process measuring points – multivariable measurement (flow, density, temperature). Space‐saving installation – no in/outlet run needs. Flow rates up to 45 000 kg/h (1654 lb/min). Volume flow calculation according to API table 53.
Transmitter features Easy operation – reduced to application needs. Fast commissioning – pre‐configured devices. Automatic recovery of data for servicing. Robust, ultra‐compact transmitter housing. Pulse output and Modbus RS485.
Nominal diameter range DN 8 to 40 (³⁄₈ to 1½")
Wetted materials Measuring tube: 1.4539 (904L)
Connection: 1.4404 (316/316L)
Measured variables Mass flow, density, temperature, volume flow, corrected volume flow
Max. measured error Mass flow (liquid): ±0.2 %
Volume flow (liquid): ±0.3 %
Measuring range 0 to 45 000 kg/h (0 to 1650 lb/min)
Max. process pressure PN 40, Class 300, 63K
Medium temperature range –40 to +125 °C (–40 to +257 °F)
Ambient temperature range –40 to +60 °C (–40 to +140 °F)
Sensor housing material 1.4301 (304), corrosion resistant
Transmitter housing material Powder‐coated die‐cast aluminium
Degree of protection IP67, type 4X enclosure
Display/Operation No local operation
Configuration via operating tools possible
Outputs Pulse/frequency/switch output (passive), phase‐shifted pulse
Inputs None
Digital communication Modbus RS485
Power supply DC 10 to 30 V
AC 20 to 28 V
Hazardous area approvals ATEX, IECEx, NEC/CEC, FM, CSA, NEPSI, UL
Other approvals and certificates 3.1 material, calibration performed on accredited calibration facilities (acc. to ISO/IEC 17025), custody transfer
PED, CRN
