Proline Promag 50P Electromagnetic flowmeter
- Brand: Endress+Hauser
- Type:
The flowmeter for highest medium temperatures with a modular electronic concept
Promag P is the preferred sensor for applications with highest requirements in a multitude of industries. Combined with the proven Promag 50 transmitter with push buttons, Promag 50P offers highly accurate measurement of liquids for a wide range of applications. Promag 50P is dedicated for chemical and process applications with corrosive liquids and high medium temperatures. Promag 50P is available in a compact or remote version.
Versatile applications – wide variety of wetted materials
Energy-saving flow measurement – no pressure loss due to cross-section constriction
Fast commissioning – application-specific Quick Setups
Safe operation – display provides easy readable process information
Fully industry compliant – IEC/EN/NAMUR
The measuring principle is virtually independent of pressure, density, temperature and viscosity
Dedicated for chemical and process applications with corrosive liquids and high medium temperatures.
Device properties
Nominal diameter: max. DN 600 (24")
All common Ex approvals
Liner made of PTFE or PFA
2-line display with push buttons
Device in compact or remote version
HART, PROFIBUS PA/DP
Benefits
Field of application
Measuring Principle
Electromagnetic
Product headline
The flowmeter for highest medium temperatures with a modular electronic concept. Dedicated for chemical and process applications with corrosive liquids and high medium temperatures.
Sensor features
Versatile applications – wide variety of wetted materials. Energy‐saving flow measurement – no pressure loss due to cross‐section constriction. Maintenance‐free – no moving parts. Nominal diameter: max. DN 600 (24"). All common Ex approvals.
Transmitter features
Fast commissioning – application‐specific Quick Setups. Safe operation – display provides easy readable process information. Fully industry compliant – IEC/EN/NAMUR. 2‐line backlit display with push buttons. Device in compact or remote version.
Nominal diameter range
DN 15...600
1/2"...24"
Max. measured error
±0.5%
±0.2% (optional)
Measuring range
0...9'600 m3/h
Max. process pressure
PN10...40
Cl 150...300
JIS 10...20K
AS 2129 Table E
AS 4087 PN16
Medium temperature range
-40...+180°C
(-40...+356°F)
Ambient temperature range
-20...+60°C
-40...+60°C (optional)
Degree of protection
IP 67 (NEMA 4x)
IP 68 (Nema 6P)
Display/Operation
Two line display with backlit
Push button
Outputs
4...20 mA
Pulse/Frequency
Status
Inputs
Status
Digital communication
HART
PROFIBUS PA
Hazardous area approvals
ATEX
FM
CSA
TIIS
