GE Masoneilan Globe Control Valves
- Brand: Masoneilan
- Type: Globe Control Valves
GE’s globe valves can handle a wide variety of process control applications. There are with many optional packages available that can help reduce noise, vibration and contain cavitation.
Features & Benefits
Balanced trim design Smaller actuators reduce overall assembly size and weight, Heavy cage-guided construction, Heavy guiding of the plug enhances throttling control performance, Few soft goods…reliability & low maintenance, Standard solutions to control noise, cavitation & valve leakage, Versatile valve technology, Robust construction, Long-term smooth operation, Process control and high process yields.
Services
Complete Service, Fast Response
Quality products combined with expert service have made GE an industry innovator for more than a century, and GE’s Masoneilan Authorized Repair Centers (MARCs) are a part of that leadership legacy. With more than 75 service facilities located in more than 30 countries worldwide -- we operate one of the most complete service networks in the industry, so you can rely on a location near you for convenience and responsiveness. In addition to having the technical expertise and product knowledge, GE’s MARC operations are outfitted with the right tooling to inspect, diagnose, repair and recalibrate your equipment.
Range of Services:
- Commissioning - Startup assistance to help confirm that equipment is performing to expected specifications
- Mechanical Inspection-Providing detailed reports of mechanical conditions
- Valve Repair-Returning your valves to “like new” condition
- Shut Down Planning-Helping to reduce outage or turnaround times
- OEM Parts-Certified original manufacturer parts that meet the highest standards
-
Asset Management-Innovative ValvKeep asset management software
Globe Control Valves Product Series
| Product Name |
Masoneilan 21000 Series Single Port Valve
|
Masoneilan 41005 Series Cage Guided Valve
|
Masoneilan 28000 Series Varipak* Valve
|
Masoneilan 80000 Series 3-Way Control Valve
|
Masoneilan 10000 Series Double Port Valve
|
| Size | 3/4” through 8” (20 through 200 mm) | 2” through 24” (50 through 600 mm) | 1” (25 mm) standard 1/2” through 3/4” (15 through 20 mm) available on request | 1” through 10” (25 through 250 mm) | 2” through 24” (50 through 600 mm) |
| Ratings & Connections | flanged: ANSI 150 – 2500, UNI-DIN 10 - 400; welded: BW or SW; screwed: NPT 3/4” through 2” (20 through 50 mm) | flanged: ANSI 150 – 2500, UNI-DIN 10 - 400; welded: BW or SW; screwed: NPT 2” (50 mm) | flanged: ANSI 150 - 600; flangeless for mounting between flanges: ANSI 150 – 2500, UNI-DIN 10 - 400; screwed: NPT 1/2” through 1” (15 through 25 mm) | flanged: ANSI 150 – 600, UNI-DIN 10 -100; threaded: NPT 3/4” through 2” (20 through 50 mm); welded: BW or SW, ANSI 900 - 2500 on request | flanged: ANSI 150 – 1500, UNI-DIN 10 - 250; welded: BW or SW; screwed: NPT 3/4” through 2” (20 through 50 mm) |
| Body Materials | carbon steel; stainless steel; chrome-moly | carbon steel; stainless steel; chrome-moly | stainless steel; monel; hastelloy C; alloy 20 | carbon steel; stainless steel; chrome-moly | carbon steel; stainless steel; chrome-moly |
| Actuators | model 87/88 multi-spring diaphragm; cylinder | model 87/88 multi-spring diaphragm; model 37/38 spring diaphragm; cylinder | integral spring diaphragm | model 87/88 multi-spring diaphragm; model 37/38 spring diaphragm; cylinder | model 87/88 multi-spring diaphragm; cylinder |
| Trim | single seat plug top guided; Lo-dB and anti-cavitation trims, single or double stage are available | balanced cage-guided trim; Lo-dB, anti-cavitation and VRT (Variable Resistance Trim), single and multiple cages are available | full stellite needle plug; multistep trim available | v-port plug | V-port or contoured plug; top and bottom guided |
| Inherent Characteristics | linear or equal percentage | linear or equal percentage | linear | linear | linear, quick opening or equal percentage |
| Description | The 21000 Series control valve is a heavy top-guided unbalanced design with noise attenuation and anti-cavitation trim options. | The 41005 Series is a heavy-duty valve design with balanced trim configurations. It offers cage guiding for added stability. | The 28000 Series Varipak* is a compact globe style valve specifically for microflow control. The Varipak includes an adjustable CV feature. | The 80000 Series is a line of three-way control valves for either combining or diverting applications. | The 10000 Series is a double-ported valve with top and bottom stem guiding and is suitable for high-pressure drop applications with dirty fluid conditions. |
| More information |
