IFM Compact mechatronic inline flow meter with backflow prevention
- Brand: IFM
- Type: SBY321
Compact mechatronic inline flow meter with backflow prevention
- Measuring range from 0.2...4 l/min
- Compact design
- Very fast response time of ≤ 10 ms
- No inlet and outlet pipe lengths required
- Independent of pressure and temperature fluctuations
For binary signal output the piston position is detected by an inductive sensor. The spring resistance leads to reliable reset of the piston to its initial position with decreasing flow. This ensures position-independent installation of the flow sensor preventing backflow.
The switch points can be easily set and fixed via a setting screw. The robust mechanical design ensures use in harsh environments.
The units are maintenance-free.
M12 connector ・ electrical design DC PNP
|
SBY321 - Flow monitor, IP 65 / IP 67, Ambient temperature 0...60 °C, M12 connector, Hysteresis:... [more] |
Connection technology
EVC001 - Socket, straight, Free from silicone, Free from halogen, Gold-plated contacts, IP... [more]
EVC002 - Socket, straight, Free from silicone, Free from halogen, Gold-plated contacts, IP... [more]
EVC004 - Socket, angled, Free from silicone, Free from halogen, Gold-plated contacts, IP 65... [more]
EVC005 - Socket, angled, Free from silicone, Free from halogen, Gold-plated contacts, IP 65... [more]
EVT064 - Socket, straight, Free from silicone, Gold-plated contacts, For hygienic and wet areas... [more]
EVT001 - Socket, straight, Free from silicone, Gold-plated contacts, For hygienic and wet areas... [more]
