IFM Continuous level measurement in harsh environments

Update: 2017/3/20      View:
  • Brand:    IFM
  • Type:    LR2050
  • Order Online
Introduction

LR level sensor in a new design with extended functions

  • Mounting adjustment enables positionindependent installation
  • Medium temperature up to 100 °C
  • Simulation function facilitates testing of the plant software
  • Automatic detection of the rod length
  • Probe lengths of 15...200 cm
Application
Harsh environment conditions or high temperatures leave the LR2050 cold. Installation in confined spaces or detection of oils using a coaxial pipe is no problem for LR, either. LR flexibly adapts to any application thanks to the installation adjustment and the modular concept.
Successful thanks to modular concept
The probes can be shortened, or changed, so the LR reduces stock-keeping and simplifies replacement.
User-friendly setting
Even before installation the user can set the sensor parameters via pushbuttons or IO-Link on the PC. Installation adjustment is made on site via pushbutton, if required.

M12 connector · IO-Link 1.1

LR2050 - Electronic level sensor, Process connection: G ¾ A, Output function: OUT1: normally... [more]
Accessories (to be ordered separately):

Rods high-grade stainless steel (316L / 1.4404)

E43225 - Probe, Probe length 150 mm
E43351 - Probe, Probe length 210 mm
E43203 - Probe, Probe length 240 mm
E43352 - Probe, Probe length 265 mm
E43226 - Probe, Probe length 300 mm
E43204 - Probe, Probe length 450 mm
E43227 - Probe, Probe length 500 mm
E43205 - Probe, Probe length 700 mm
E43207 - Probe, Probe length 1000 mm
E43208 - Probe, Probe length 1200 mm
E43209 - Probe, Probe length 1400 mm
E43210 - Probe, Probe length 1600 mm
E43353 - Probe, Probe length 2000 mm

Coaxial pipes stainless steel (304S15 / 1.4301)

E43230 - Coaxial pipe, Length 150 mm
E43354 - Coaxial pipe, Length 210 mm
E43211 - Coaxial pipe, Length 240 mm
E43355 - Coaxial pipe, Length 265 mm
E43228 - Coaxial pipe, Length 300 mm
E43212 - Coaxial pipe, Length 450 mm
E43229 - Coaxial pipe, Length 500 mm
E43213 - Coaxial pipe, Length 700 mm
E43214 - Coaxial pipe, Length 1000 mm
E43215 - Coaxial pipe, Length 1200 mm
E43216 - Coaxial pipe, Length 1400 mm
E43217 - Coaxial pipe, Length 1600 mm
E43356 - Coaxial pipe, Length 2000 mm
E43218 - Coaxial pipe, Length 450 mm
E43219 - Coaxial pipe, Length 700 mm
E43220 - Coaxial pipe, Length 1000 mm
E43221 - Coaxial pipe, Length 1600 mm

Coaxial pipes, slotted stainless steel (304S15 / 1.4301)

E43333 - Coaxial pipe, Length 700 mm
E43334 - Coaxial pipe, Length 1200 mm

Flange plates stainless steel (303 / 1.4305)

E43201 - Flange plate, according to DIN 24557, Ambient temperature 0...80 °C
E43206 - Flange plate, according to DIN 24557, Ambient temperature 0...80 °C
E43202 - Flange plate

IO-Link accessories

E30396 - IO-Link interface, for parameter setting and analysis of units with max. 65 mA current... [more]
E30398 - Memory plug, Parameter memory for IO-Link sensors, Storage capacity: 2 Kbytes, IP... [more]
QA0001 - LINERECORDER SENSOR, Version 4.2, Software for clear online and offline parameter... [more]
