Bently Nevada Snapshot IS Portable Data Collector

Update: 2016/5/30      View:
  • Brand:    Bently Nevada
  • Type:
  • Order Online
Introduction

The Snapshot™ IS is intended for periodic manual collection of data as part of a plant asset management program. The instrument offers a single vibration channel plus speed/phase input. Its ATEX Directive II Ga Ex ia IIC T4 (Ta -20°C to +S0°C) , and Directive I Ma Ex ia (Ta 0°C to +S0°C) hazardous area approval permits use in Intrinsically Safe environments without the need for a special "hot work" permit. Snapshot™ IS interfaces with the Bently Nevada's System 1™ software platform. The user configures point and route information in System 1, downloads the configuration to the Snapshot IS, and transfers collected data back to System 1 for display, trending, and storage.


Features and Benefits

  • Snapshot IS provides single-channel data acquisition with a second channel for phase and speed input.
  • Lightweight design allows single-handed use for extended periods of time with minimal physical effort.
  • IPS4 rating permits use in harsh environments.
  • Removable NiMH battery provides 6 to 8 hours of use between charges.
  • Polycarbonate/ABS case design provides high impact resistance and durability.
  • 1/8 VGA display (backlit) and integral touchscreen provide a convenient user interface.
  • Ergonomically designed keypad permits simple operation with either the left or right hand, even with gloves on.
  • Intuitive user interface simplifies operation.
  • 16 MB of standard on-board memory accommodates large data collection schedules.
  • Unit supports a wide variety of rack buffered measurement types and signal processing options, including:
    • Proximity probes
    • Velocity transducers
    • Accelerometers
    • Temperature measurements
    • Numeric data
    • Manually keyed notes
    • User-configurable dynamic inputs
    • REBAM® transducers

The Snapshot IS data collector uses System 1 host software (refer to System 1 Specifications and Ordering Information, p/n 14S146-01) for permanent storage of all collected data and for system configuration functions.
