E+H 4-20ma Temperature Transmitter ITEMP TMT181,TMT182

Update: 2018/3/28      View:
  • Brand:    Endress+Hauser
  • Type:
  • Order Online
Introduction

Specifications

E+H 4-20ma Temperature Transmitter ITEMP TMT181,TMT182
high quality,original and brandnew,fast shipping

E+H 4-20ma Temperature Transmitter ITEMP TMT181,TMT182
1.High accuracy in total ambient temperature range
2.Galvanic isolation
3.Output simulation
4.EMC to NAMUR NE 21, CE





Product Description

 Features:

  • High accuracy in total ambient temperature range

  • Fault signal on sensor break or short circuit, NAMUR NE 43 compliant

  • Ex certification: ATEX Ex ia and dust ex zone 22 in compliance with
    EN 50281-1; FM IS; CSA IS

  • EMC to NAMUR NE 21, CE

  • Configuration during measurement using configuration kit

  • Galvanic isolation

  • Output simulation



--Technical Information



Measuring Principle Head transmitter
Input 1 x RTD, TC, Ohm, mV
Output 1 x analog 4...20 mA
Auxiliary power supply 8...35 V DC (standard-version)
8...30 V DC (Ex-version)
Communication PCP (pc-programmable)
Installation Terminal head form B
Accuracy (Pt100, -50...200 °C) <= 0,2 K
(Pt100, -58...392 °F) <= 0,4 °F
Galvanic isolation yes
Certification UL Ex IS, NI
GL marine approval
GOST Ex i
ATEX II1G EEx ia IIC T4/T5/T6
FM IS,NI,Class I,Div.1+2,Group ABCD
CSA IS,NI,Class I,Div.1+2,Group ABCD
ATEX II3G Ex nA II T4/T5/T6
ATEX II3D
ATEX II1G EEx ia IIC T6, II3D
ATEX II3G Ex nA II T6, II3D
FM+CSA IS,NI,Class I,Div.1+2,Group ABC
CSA General Purpose
NEPSI Ex ia IIC T4-T6
NEPSI Ex nA II T4-T6





--Field of application



  • PC programmable (PCP) temperature head transmitter for converting various input signals into a scalable 4 to 20 mA analog output signal

  • Input: Resistance thermometer (RTD), thermocouple (TC), resistance transmitter (ohm), voltage transmitter (mV)

  • Configuration using a PC with configuration kit (PC-software ReadWin 2000)
